Torsion Axle, 6,000 lb Capacity, 70" Frame Center, 89.25" Hub Face, 76.68" Outside Bracket, 35* Starting Angle, Galvanized, Load Rite OEM Axle

Specifications

Axle Type: Torsion Axle

Weight Capacity: 6,000 lbs

Hub Face: 89.25"

Frame Center: 70"

Outside Bracket: 76.68"

Starting Angle: 35*

Spindle Size: 1-3/4" x 1-1/4" (Standard w/Super-Lube zerc fitting)

Finish/Material: Galvanized

Includes Brake Flange: No

Removeable Spindles or Trail Arm: Removeable Spindles

Includes Hubs: Bare Spindles

Brand/Manufacturer: Tie Down, Model: Eliminator

Alternate Part #: 6226.02

Inner Bearing #: 25580

Outer Bearing #: LM67048

Notes: Used on current Load Rite 96" Single Axle and Tandem Trailers

Replaces: Old Load Rite #6227.55

Used On: Load Rite 96" Single Axle and Tandem Trailers

SuperLube Lubrication
This Axle's Spindle is equipped with TDE’s SuperLube Lubrication System. The bearings can be periodically lubricated without removing the hubs from the axle. The advantage to this system is that new grease saturates the inner bearing and outer bearing while pushing out the old grease, unlike systems that just push new grease on top of old grease.
1. Remove the rubber plug from the grease (hub) cap.
2. Use a standard grease gun onto the grease fitting located at the end of the spindle, making sure the grease gun nozzle is engaged on the fitting tightly.
3. Pump grease into the fitting, while slowly turning the wheel. Grease will flow out of the hub around the spindle.
4. When the grease appears to be the new clean grease, remove the grease gun and wipe off any excess grease.
5. Replace the rubber plug in the cap.



All Tie Down Axles are proudly made in the USA!
