Galvanized 6,000 Lbs. Capacity Torsion Axle, Hub Face = 89.25", Outside Bracket = 75.68", Frame Center = 70", Down Angle = 35°. With Bare Spindles (Load Rite # 6226.02)

With 6 Lug Pre-Greased Hubs Installed

Frame Center: 70"

Outside Bracket: 76.68"

Load Rating: 6,000 lbs.

Track Length: 89.25"

Spindle Size: 1-3/4" x 1-1/4" (Standard w/Super-Lube zerc fitting)

Inner# 25580 and Outer Bearing #LM67048

Load Rite Trailer OEM Axle

Used on current Load Rite 96" Single Axle and Tandem Trailers

Old Load Rite # 6227.55, new Load Rite # 6226.02

SuperLube Lubrication
This Axle's Spindle is equipped with TDE’s SuperLube Lubrication System. The bearings can be periodically lubricated without removing the hubs from the axle. The advantage to this system is that new grease saturates the inner bearing and outer bearing while pushing out the old grease, unlike systems that just push new grease on top of old grease.
1. Remove the rubber plug from the grease (hub) cap.
2. Use a standard grease gun onto the grease fitting located at the end of the spindle, making sure the grease gun nozzle is engaged on the fitting tightly.
3. Pump grease into the fitting, while slowly turning the wheel. Grease will flow out of the hub around the spindle.
4. When the grease appears to be the new clean grease, remove the grease gun and wipe off any excess grease.
5. Replace the rubber plug in the cap.



All Tie Down Axles are proudly made in the USA!
